RS-232 / IR port:
Ports: 3 x bidirectional and 2 x unidirectional
Baud rate 1200 – 115200 bit/sec
Data bits 7, 8
Parity Even, Odd, None
Stop bits1, 2
IR frequency400 Hz to 500 KHz
Connector3 pin screw block
IR learn:
IR Learn frequency 1 KHz to 150 KHz
Input / Output:
Ports 8 x I/O
Input trigger low< 1VDC
Input trigger high> 4VDC
Output type Open drain
Isolated output No
Max voltage load24 VDC
Max current 0.5 A
Connector 4 pin screw block
Relay Output:
Voltage max30 VDC
Current max0.5 A
Connector 2 pin screw block
Network (LAN):
Speed 10 / 100 Mbit
Duplex modes Half or Full
DHCP Default off
Default IP 192.168.254.252
Default gateway 192.168.1.1
Default subnet mask 255.255.255.0
PoE – Power over Ethernet:
TanGo is IEEE 802.3 compliant. This entails it will work with both 802.3af and 802.3at devices
Note: PoE Injector not included. Use PoE Injector (Product Item number: 302-000508)
General:
Width:218 mm
Height:37 mm
Depth:70 mm
Width:8,58 inches
Height:2,76 inches
Depth:1,46 inches
Weight:0.5 kg.
Shipping weight:1.0 kg.
Shipping dimension: 282 mm / 188 mm /
(W/D/H)55 mm
Storage temperature -20 °C to 50 °C
Storage moistureNon-condensing
Operation temperature 0 °C to 30 °C
Operation moisture Non-condensing
Product number:
310-0305TanGo
Approvals:
IEC/EN61000-6-1
IEC/EN61000-6-2
FCCPart 15, Class A
CE
